Application: Suitable for producing PET/PI/Non-woven fabric substrate medical tapes.
Note: Specific parameters will be customized based on customer's process requirement.
| Machine Composition | |
|---|---|
| Unit | Qty |
| Double-station unwind | 1 set |
| Comma bar coater | 1 set |
| Drying unit | 2m/section, 2m*8=16m in total |
| Heat/Cooling unit | 1 set |
| Single-station unwinder | 1 set |
| Double-station rewind | 1 set |
| Electrical control system | 1 set |
| Main Technical Parameters | |
| Machine speed | 0~20m/min, designable |
| Coating speed | 1~20m/min (Depends on substrate properties) |
| Substrate width | Max. 550mm |
| Substrate type | PET, PI, NON-WOVEN fabric |
| Coating type | Comma bar coating |
| Oven length | 4m/section, designable |
| Heating type | Electricity, natural gas, thermal oil, steam, etc. |
| Compressed air | Min. pressure 6kg/cm² (Filtration/Cleaning treated) |
| Tension control range | 3~30KG (whole web load) |
| Tension precision | ±0.2KG |
| Unwind/Rewind Diameter | Unwind Max.φ400mm / Rewind Max.φ800mm |
| Control Voltage | 220VAC, 1P ±7%, 50HZ±2% |
