| Application | Commodity, Machinery & Hardware, Textile, Alcohol, Toy, Chemical, Apparel, Gifts & Arts, Dining, Medical, Food, Cosmetics |
| Driven Type | Electric |
| Automatic Grade | Automatic |
| Cartoning Speed | 20-70 Cartons/Min (Depending on Carton Quality) |
| Carton Size Range | (70-200)mm*(35-120)mm*(14-70)mm |
| Power Supply | 380V, 50Hz, 3 Phase |
| Machine Type | Horizontal Cartoning Machine |
The automatic cartoning machine is a horizontal type box packing machine developed through advanced technologies. It integrates light, electricity, pneumatics, and machinery into one high-tech system. This machine offers robust production performance and high working efficiency, maintaining stability even during high-speed operations.
Commonly applied in foodstuff, pharmaceuticals, daily chemicals, and hardware industries, it features a user-friendly touch screen for speed control and automatic feeding adjustments. The system includes online product detection, batch number printing, mechanical sealing (or hot melt glue), and automatic rejection of unqualified products.
| Parameter | Specifications |
|---|---|
| Cartoning Speed | 20-70 cartons/min |
| Carton Quality | 250-350g/m² |
| Leaflet Quality | 60-70g/m² |
| Leaflet Fold | 1-4 folds |
| Working Pressure | ≥0.6mpa |
| Air Consumption | 120-160L/min |
| Main Motor Power | 2.5kw |
| Machine Dimensions | 3100×1100×1550mm |
| Machine Weight | Approx. 1400kg |
