An AC converter control is used for both speed and quantity of glue feeding, supporting both automatic synchronous tracking and manual control.
✓
Equipped with an intelligent PID temperature control system, ensuring precise control with an error margin within 1 degree Celsius.
✓
The glue melting oven features an anti-sticking layer, effectively preventing hot melt adhesive carbonization.
Machine Color: Silver Grey
Total Power: 380V 50HZ 38KW
Machine Weight: 5 Ton
Overall Size: 5000mm * 2300mm * 1700mm
Coating Mode: Knife Coating
Coating Weight Range: 10-100g/sqm
Uniformity: ≤ ±0.002mm
Max Working Speed: 50-150m/min
Roller Width: 700-2100mm
Max Diameter of Unwind: 1000mm
Max Diameter of Rewind: 700mm
Glue Melting Speed: 130kg/h (EVA, 3000CPS, 165°C)
Max Temperature: 230°C
Frequently Asked Questions
How is the after-sales service for these machines?
Our machines come with a one-year guarantee and life-long maintenance. We have a dedicated team for after-sales support and can arrange engineers to provide service when needed.
Are you a manufacturer or a trading company?
We are a professional factory with nearly 10 years of specialized experience in this field.
How can I visit your facility?
Our facility is located in China near major transport hubs. You can fly directly to the nearest regional airport or utilize the high-speed rail network to reach us easily.
What quality control measures are in place?
Quality is the foundation of our development. Since our inception, we have focused strictly on quality management. Our hot melt adhesive coating equipment has successfully passed CE and SGS certifications.
What information is needed to receive a quotation?
Please provide details regarding your requirements, such as the substrate type, adhesive material, and preferred coating width. Providing pictures or design drawings helps our designers analyze your needs for an exact specification.
Are videos and detailed component lists available?
Yes, we can provide detailed operation videos, full component specifications, and a breakdown of the working process upon request.
